HELU-S-PK-CU Tubular compression cable lugs - straight

  • Code type indicates the required hexagonal clamping insert.
  • Compression instruction and instruction for assembly see chapter "Technical information".
  • Tubular cable lugs HELU-S-PK-CU
  • Non-insulated tubular cable lugs in eye type design for conductor arrangement RM.

Ringform

Artikel-Nr.

Typ

Querschnitt

mm²

a

mm

d

mm

b

mm

l

mm

Kennzahl
Typ

Gewicht

kg / 1000

Stück

VPE
Stück

Netto EUR/100 Stück bei Abnahme von

bis 100

101 - 500

501 - 1000

907679

HELU-S-PK-CU 6-8

6,0

8,4

3,5

13,0

26,0

5

3,1

100

21,90

20,30

15,60

907682

HELU-S-PK-CU 10-8

10,0

8,4

4,4

13,0

28,0

6

3,8

100

43,10

40,00

30,80

907683

HELU-S-PK-CU 10-10

10,0

10,5

4,4

15,0

29,0

6

3,8

100

43,10

40,00

30,80

907684

HELU-S-PK-CU 16-5

16,0

5,3

5,5

13,0

36,0

8

12,2

100

52,90

49,10

37,80

907688

HELU-S-PK-CU 16-12

16,0

13,0

5,5

19,0

40,0

8

13,5

100

62,40

58,00

44,60

907693

HELU-S-PK-CU 25-16

25,0

17,0

7,0

22,0

45,0

10

19,9

100

75,10

69,80

53,70

907694

HELU-S-PK-CU 35-6

35,0

6,4

8,2

17,5

42,5

12

31,2

100

86,50

80,30

61,80

907698

HELU-S-PK-CU 35-16

35,0

17,0

8,2

28,0

47,0

12

31,4

100

93,10

86,40

66,50

907699

HELU-S-PK-CU 35-20

35,0

21,0

8,2

30,0

53,0

12

37,3

100

100,60

93,40

71,80

907700

HELU-S-PK-CU 50-6

50,0

6,4

9,8

20,0

52,0

14

46,7

100

130,70

121,40

93,40

907704

HELU-S-PK-CU 50-14

50,0

15,0

9,8

26,0

53,5

14

49,4

100

130,80

121,50

93,40

907706

HELU-S-PK-CU 50-20

50,0

21,0

9,8

30,0

55,6

14

55,6

100

150,50

139,80

107,50

907710

HELU-S-PK-CU 70-14

70,0

15,0

11,3

24,0

55,5

16

60,0

50

169,60

157,50

121,20

907712

HELU-S-PK-CU 70-20

70,0

21,0

11,3

31,0

61,0

16

69,9

50

193,80

180,00

138,40

907713

HELU-S-PK-CU 95-8

95,0

8,4

13,5

28,0

65,0

18

93,6

50

222,50

206,60

158,90

907714

HELU-S-PK-CU 95-14

95,0

15,0

13,5

28,0

65,5

18

94,3

50

226,00

209,90

161,40

907717

HELU-S-PK-CU 120-8

120,0

8,4

15,5

31,0

70,0

20

113,5

50

269,50

250,20

192,50

907718

HELU-S-PK-CU 120-14

120,0

15,0

15,5

31,0

70,0

20

114,1

50

274,30

254,70

196,00

907721

HELU-S-PK-CU 150-8

150,0

8,4

17,0

34,0

79,0

22

164,0

25

376,90

350,00

269,20

907723

HELU-S-PK-CU 150-14

150,0

15,0

17,0

34,0

78,0

22

164,9

25

356,40

331,00

254,60

907725

HELU-S-PK-CU 185-8

185,0

8,4

19,0

37,0

83,0

25

185,0

25

451,20

419,00

322,30

907727

HELU-S-PK-CU 185-14

185,0

15,0

19,0

37,0

82,0

25

189,6

25

411,00

381,60

293,60

907729

HELU-S-PK-CU 240-10

240,0

10,5

21,5

42,0

92,0

28

271,0

20

665,40

617,90

475,30

907730

HELU-S-PK-CU 240-14

240,0

15,0

21,5

42,5

92,0

28

267,3

20

585,70

543,80

418,30

907732

HELU-S-PK-CU 300-10

300,0

10,5

24,5

48,5

104,0

32

348,0

10

847,60

787,10

605,50

907733

HELU-S-PK-CU 300-12

300,0

13,0

24,5

48,5

104,0

32

345,0

10

847,60

787,10

605,50

907734

HELU-S-PK-CU 300-14

300,0

15,0

24,5

48,5

104,0

32

346,0

10

813,20

755,10

580,80

907735

HELU-S-PK-CU 400-10

400,0

10,5

27,5

55,0

117,0

38

715,5

5

1469,70

1364,70

1049,80

907736

HELU-S-PK-CU 400-12

400,0

13,0

27,5

55,0

117,0

38

717,0

5

1469,70

1364,70

1049,80

907737

HELU-S-PK-CU 400-14

400,0

15,0

27,5

55,0

117,0

38

719,8

5

1469,70

1364,70

1049,80

907738

HELU-S-PK-CU 500-12

500,0

13,0

31,0

60,0

130,0

42

869,2

5

2471,10

2294,60

1765,10

907739

HELU-S-PK-CU 500-14

500,0

15,0

31,0

60,0

130,0

42

875,0

5

2471,10

2294,60

1765,10

907740

HELU-S-PK-CU 500-16

500,0

17,0

31,0

60,0

130,0

42

889,0

5

2471,10

2294,60

1765,10

907741

HELU-S-PK-CU 625-12

625,0

13,0

34,5

63,0

135,0

44

842,7

5

2845,90

2642,60

2032,80

907742

HELU-S-PK-CU 625-14

625,0

15,0

34,5

63,0

135,0

44

838,9

5

2684,30

2492,50

1917,30

907743

HELU-S-PK-CU 625-16

625,0

17,0

34,5

63,0

135,0

44

820,5

5

2684,30

2492,50

1917,30

907745

HELU-S-PK-CU 800-14

800,0

15,0

16,0

75,0

165,0

100

1486,0

2

4226,50

3924,60

3018,90

907746

HELU-S-PK-CU 800-16

800,0

17,0

40,0

75,0

165,0

100

1494,2

2

4226,50

3924,60

3018,90

907748

HELU-S-PK-CU 1000-16

1000,0

17,0

44,0

83,0

167,0

58

1937,0

2

5491,70

5099,40

3922,60
